| Manufacturer | Olympus |
|---|---|
| Model | 20700 |
| Megapixels | 10 |
| Zoom | 4x - 28mm-112mm (35mm equivalent) |
| Screen Size | 3" |
| Screen Resolution | 610,000 Dot |
| Tilt/Swivel LCD | No |
| Touchscreen | No |
| Screen Type | OLED |
| Movie Mode | HD (720) |
| Image Stabilization | Yes |
| Battery Type | Li-Ion |
| Manual Controls | Yes |
| Raw | Yes |
| Viewfinder | Optional Electronic |
| Weather-sealed | No |
| Memory Card | SD / SDHC / SDXC |
-
10 MEGAPIXEL
The 10 million pixels in the high-resolution CCD create superior image quality. Create poster-sized prints without losing a single detail. -
LARGE, HIGH-SENSITIVITY CCD
Providing the best image quality ever in a compact Olympus camera, the large 1/1.63-inch CCD enables greater dynamic range and smoother gradations from highlights to shadows. -
4X IZUIKO ZOOM LENS
Based on the standards of Olympus DSLR lenses, the wide aperture of the iZuiko f1.8-2.5 allows a rich and vibrant range of photographic expression. It allows faster shutter speeds in low light – and it allows for a shallower depth of field than most compact point-and-shoot cameras. -
HD MOVIE 720P
A simple, one-touch button allows you to record movies with amazing clarity in high-definition, right from your camera. -
ACCESSORY PORT
The XZ-1 includes a port for accessories including the SEMA-1 Microphone adapter set and the VF-2 live-finder, a detachable electronic viewfinder. The viewfinder easily slides onto the camera's accessory port and hot shoe to provide 1.15x magnification for a 100% field of view. The VF-2 rotates up 90 degrees which is useful when shooting subjects from challenging angles. The external accessory port also allows for connection with the SEMA-1 external microphone adapter set for enhanced audio capture. -
IN-CAMERA ART FILTERS – MOVIE AND STILL IMAGES
With six in-camera Art Filters (Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama and Dramatic Tone) you can explore your artistic side while taking both still shots and HD video. The Art Filters can be applied as you shoot, no additional software required. -
DUAL IMAGE STABILIZATION
Dual Image Stabilization combines Sensor-Shift Image Stabilization with high ISO sensitivity and fast shutter speeds to capture crisp, clear images in any situation. -
NEW EASY-TO USE-LIVE GUIDE CONTROL
Seeing the results before you shoot can change the way you take a picture. Want more vivid or muted color in your shot? Want warmer or cooler hues? Want a brighter or darker subject, or a sharper or softer background? Or maybe you want to capture the fast-moving action of your subject with a little artistic blur, or perhaps freeze the action? Simply set the camera to iAuto, press OK to engage Live Guide, then press the up and down arrows on the back of the E-PL1 to easily slide through numerous photographic effects. Make adjustments and watch the LCD as the effects are made live -- before the image is captured! Live Guide also features a Tips section on how to compose a shot or shoot kids, pets, flowers and more. -
IN-CAMERA PANORAMA
Captures three images and stitches them together to create one amazing panoramic picture by simply pressing the shutter button and slowly panning across a panoramic scene. -
AF LIVE VIEW WITH AF TRACKING
AF Live View works as seamlessly as a point-and-shoot to display subjects, in focus, on the LCD the instant the shutter is pressed half way. AF Tracking locks your subject into focus right on the LCD, and constantly adjusts focus and brightness whether you or your subject is moving. With this mode, a simple push of the AF button and shutter release enables you to keep fast-moving and unpredictable subjects in focus. -
ADVANCED FACE DETECTION
Face Detection automatically focuses on your subjects' faces and optimizes exposure for sharp, brilliant portrait pictures. -
TRUEPIC V IMAGE PROCESSOR
In addition to more detail, the image sensor, combined with the next-generation TruePic V Image Processor, delivers excellent dynamic range, accurate color fidelity and reduced noise, all the way up to 3200 ISO. -
UNDERWATER HOUSING
The XZ-1’s compact design makes it the perfect companion for all of your dive trips. The PT-050 underwater case has been customized for the XZ-1 and is waterproof to a depth of 40 meters (approximately 130 feet). With its durable, high-quality polycarbonate construction, this Olympus housing protects the camera from water while also cushioning it from knocks and bumps on land.
| Product Type | Product type | Compact digital camera |
| Memory | SD Memory Card(SDHC/SDXC compatible) ~64GB | |
| Screen size | 1/1.63” | |
| Effective Pixels number | Effective Pixels number | 10M (3664 x 2752) |
| Lens | Structure | 11elements in 8groups |
| Aspheric | 6 sides | |
| Focal length(35mm equivalent) | 6.0mm to 24.0mm(28mm to 112mm) | |
| Maximum aperture | 1.8-2.5 | |
| Optical zoom | 4x | |
| Digital zoom | 4x | |
| Imaging range | Normal:60cm to infinity, Macro:W:10cm to infinity,T:30cm to infinity. Super Macro:1cm to TBD,Wide-angle edge fixing |
|
| Image Pickup Unit | Product type | 1/1.63" High-Sensitivity CCD |
| Total no. of pixels | 4072x2784 | |
| Aspect ratio | 4:3 | |
| Recording(Still) | Recording format | DCF, DPOF compatible/Exif, PRINT Image Matching III |
| File format | RAW (12-bit lossless compression), JPEG, RAW+JPEG | |
| Recording image size | [RAW] 3648 x 2736 pixels | |
| [JPEG] 3648 x 2736 pixels - 640 x 480 pixels | ||
| File Size | RAW: 3648 x 2736 (approx. 1/1.5 lossless compressed) Approx. 17MB | |
| Large: 3648 x 2736 Fine (1/4 compressed) Approx. 5.5MB | ||
| 3648 x 2736 Normal (1/8 compressed) Approx. 3.1MB | ||
| Middle: 3200 x 2400 Fine (1/4 compressed) Approx. 4.4MB | ||
| 3200 x 2400 Normal (1/8 compressed) Approx. 1.9MB | ||
| 2560 x 1920 Fine (1/4 compressed) Approx. 2.4MB | ||
| 2560 x 1920 Normal (1/8 compressed) Approx. 1.3MB | ||
| 1600 x 1200 Fine (1/4 compressed) Approx. 1MB | ||
| 1600 x 1200 Normal (1/8 compressed) Approx. 0.5MB | ||
| Small 1280 x 960 Fine (1/4 compressed) Approx. 0.7MB | ||
| 1280 x 960 Normal (1/8 compressed) Approx. 0.4MB | ||
| 1024 x 768 Fine (1/4 compressed) Approx. 0.5MB | ||
| 1024 x 768 Normal (1/8 compressed) Approx. 0.3MB | ||
| 640 x 480 Fine (1/4 compressed) Approx. 0.2MB | ||
| 640 x 480 Normal (1/8 compressed) Approx. 0.2MB | ||
| Recording(Movie) | Recording format | AVI Motion JPEG(30fps) |
| Movie Mode | HD: 1280(H)x720(V) Aspect 16:9 SD: 640(H)x480(V) Aspect 4:3(VGA) |
|
| Compression Ratio | 1/12 | |
| File Size | Max 2GB(limited by AVI format) | |
| Maximum Recording Time | HD: 7min, SD: 14min | |
| Recording(Sound) | Recording format | Wave Format Base Stereo PCM/16bit, 44.1kHz |
| Maximum Recording Time | Picture with Sound: 30sec Movie: depend on Movie Recording Time |
|
| Live View | Type | Image Sensor type |
| Field of view | 100% | |
| Display Mode | Normal Mode | |
| Grid Line + Histogram Mode | ||
| OFF Mode | ||
| Magnification Ratio | Not available | |
| Monitor information | Aperture value, Shutter speed, Auto Bracket, AF mode, IS, Shooting Mode, Battery Check, My Mode, Face Detection, Histogram, Number of storable still pictures, Record mode, ISO, Sequential shooting, Self-timer, White Balance |
|
| Display of Face Detection | Max 8 frames of face detection can be displayed | |
| AF | Imager AF | |
| Image stabilizer | System | Built in (Imager shift image stabilizer) |
| Mode | 2 dimensional activation, OFF | |
| Effective compensation range | Approx.2EV steps | |
| Shutter speed range | 2 - 1/2000 sec. (Not available when Bulb is selected) | |
| IS for Movie | Electronic Image Stabilization with Multi-Motion function | |
| Monitor | Product type | OLED |
| Size | 3.0 inches (3:2) | |
| Total no. of pixels | 614,000dots | |
| Playback field of view | 100% | |
| Brightness control | +2 levels and -2 levels | |
| Colour balance | Not available | |
| Focusing | AF system | Imager Contrast Detection AF system |
| Focus mode | Single AF (AF) / Manual Focus (MF) / Macro mode / SuperMacro mode / AF tracking (TR) | |
| Focusing point | 11-area multiple AF with the contrast detection system (Auto, selectable in option) | |
| Focusing point selection | Auto from all 11 area, Single area from 11 area Auto from almost all area when Face detection is ON Free selection (from 225points) when Magnified View Mode is selected |
|
| AF illuminator |
Available | |
| Focus tracking | Available | |
| Manual Focus Assist | When rotation of Control dial is detected under MF mode, LV is magnified automatically | |
| Shooting Modes | P(Program Auto),iAUTO,A(Aperture priority).S(Shutter priority),M(Manual shooting),C(Custom shooting), | |
| Low Light,Art Filter,SCN(Scene) | ||
| Exposure Control | Metering system | TTL Image Sensor metering system |
| (1) Digital ESP metering (324-area multi pattern metering) (2) Center weighted average metering (3) Spot metering | ||
| Metering range | EV0-17 | |
| Exposure mode | (1) i Auto (2) P: Programme AE (3) A: Aperture priority AE | |
| (4) S: Shutter priority AE (5) M: Manual (6) Low Light (7) Scene select AE (8) Art Filter | ||
| Scene select AE | Portrait, e-Portrait, Landscape, Night Scene, Night + Portrait, Indoor, Self Portrait, Sport, Sunset, Fireworks, | |
| Multi Exposure, Cuisine, Document, Beach & Snow, Under Water Wide, Under Water Macro, Pet, Panorama | ||
| ISO sensitivity | AUTO: ISO 100 - 800 / Manual ISO 100 - 6400, 1/3 EV steps, Movie ISO 200-1600, Low light ISO 100-3200 | |
| Exposure compensation | ±2 EV in 1/3EV steps | |
| AE lock | Non available | |
| Exposure bracketing | Available | |
| Metering standard value adjustment | ||
| White Balance | Auto WB system | Available |
| Preset white balance | 6 settings (3000K - 7500K) Lamp (3000K), Fluorescent 1 (4000K), Fluorescent 2 (4500K), Daylight (5300K), Cloudy (6000K), Shade (7500K) , Under Water Auto, One Touch WB |
|
| White balance compensation | ±7 steps in each A-B/G-M axis (in Auto WB / Preset WB mode / One touch WB) | |
| CWB (Kelvin setting) | 1 setting can be registered at Kelvin temperature (2000K - 14000K) | |
| One-touch white balance | Available | |
| White balance bracketing | 3 frames in 2, 4, 6 steps selectable in each A-B/G-M axis. | |
| Colour Mode | Colour space | sRGB |
| Picture Mode | Mode | Vivid, Natural, Portrait, Muted, Monotone |
| Adjustment parameter | Contrast, Sharpness and Saturation level available in 5 steps for Vivid, Natural, Portrait and Muted | |
| Contrast and Sharpness level available in 5 steps for Monotone. | ||
| Filter effect | Yellow, Orange, Red or Green filter available for Monotone | |
| Picture tone | Sepia, Blue, Purple or Green tone available for Monotone | |
| Gradation | 4 levels (Auto, High key, Normal, Low key) | |
| Shutter | Shutter speed | 60 - 1/2000 sec. |
| Bulb: up to 16 min. | ||
| 1/3 steps | ||
| Self-timer | Operation time: 12 sec., 2 sec. (cancel available) | |
| Remote cable release | Available (with optional RM-UC1 Remote cable.) | |
| Drive | Drive mode | Single-frame shooting, Sequential shooting, High-speed Sequential shooting1,High-speed Sequential shooting2,Self-timer |
| Sequential shooting speed | Approx. 2 frames/sec. in sequential shooting | |
| Max. recordable pictures | RAW mode: Max. 8 frames. | |
| on sequential shooting | JPEG mode: Depends on compression ratio and no. of pixels (Large normal mode: approx. 23 with Toshiba Super High Speed type "Class 6" 4GB) |
|
| Flash | Built-in flash | Available |
| Compatible external flash | E-system Flash(FL-36R, FL-20, FL-14,FL-50R) *FL-50R(Can only be used with wireless. Cannot attach to body) |
|
| Flash mode of External Flash | Auto, Red-eye reduction, Red-eye reduction slow sync., Slow sync at 1st curtain, Slow sync at 2nd curtain, Fill-in, Off. | |
| Flash intensity control | Up to ±2 EV in 0.3 EV steps | |
| Art Filter | Mode | Pop Art, Soft Focus, Grainy Film, Pin Hole, Diorama, and Dramatic Tone |
| Multi Exposure | Number of picture | 2 frames |
| Functions | Auto gain, | |
| Multi Aspect | Aspect Ratio | 4:3/3:2/16:9/6:6 |
| Live control | Information (shooting) | Battery information, Shooting mode, Shutter speed, Aperture value, Exposure compensation value, ISO sensitivity, |
| Live Guide | Exposure compensation indicator, Exposure indicator, Flash intensity compensation indicator, Date, Auto BKT setting, | |
| WB, Record mode, Flash Status, Image size, Drive mode, Flash intensity compensation value, Metering mode, | ||
| Recordable still image number, Focusing mode, AF frame, IS activating mode, Face detection, My Mode, | ||
| Multi Exposure, Aspect Ratio | ||
| Live Guide | Color satuturation, Color image, Brightness, Blur Background, Shooting tips | |
| Playback | Playback mode | Single-frame |
| Information Display | ||
| Index Display(25 frames, Calendar) | ||
| Close-up (1.1 - 10X) | ||
| Movie (w/sound, FF/REW/Pause) | ||
| Slideshow(Still/Movie/Still+Movie, Slide show w/BGM/BGM+Sound/Sound) | ||
| Information display | Histgram,Shooting information,OFF | |
| Menu | Languages | 39 |
| Reset & custom setting | My mode | 1 setting recordable |
| Image Editing | Erasing function | Single frame, All, Selected frames(from Index) |
| Protect function | Single frame | |
| RAW picture editing | RAW development based on settings of the camera(including Art Filter) | |
| JPEG editing | Shadow adjustment, Red-eye fix, Trimming, Monotone, Sepia, Saturation (colour depth), Resize (producing another file, 1280x960, 640x480, 320x240), e-portrait | |
| Print function | Print reservation (DPOF), Direct print (PictBridge compatible) | |
| Input/Output | PC interface | USB 2.0 High Speed for storage through Multi-connector(MTP mode is available) |
| TV interface | HDMI(HD/Stereo Sound), VIDEO-OUT(SD/Mono Sound) | |
| USB/Video connector | Dedicated multi-connector (Video: NTSC/PAL selectable, Optional Remote cable RM-UC1, USB cable is available) | |
| HDMI | Mini HDMI type-D | |
| Flash attachment | Hot shoe | |
| DC-in | Yes(Multi terminal) | |
| Accessory attachment | Accessory port | |
| Accessories Chart | External Fkash | FL-36R, FL-20, FL-14,FL-50R(Can only be used with wireless.Cannot attach to body) |
| Viewfinder | VF-2 | |
| External microphone | SEMA-1 + ME51SW | |
| Armlight | MAL-1 | |
| Accessory for underwater photography | PT-050 | |
| AC cable | F-3AC | |
| Remote Cable | RM-UC1 | |
| Charger | LI-50C | |
| Compatible OS | Windows XP SP2, Windows XP x64Edition, Windows Vista, Windows Vista SP1, Windows 7, Mac OS 10.3-10.6 | |
| Power Requirements | Battery | Li-50B (included) |
| Sleep mode | Available (20sec, 1min, 3min, 5min) | |
| No. of recordable pictures (with 50% flash light) | Approx. 320 shots | |
| Power battery holder | Non available | |
| Memory | Internal memory (for shooting) | 54.6MB |
| Dimensions/Weight | Dimensions | 110.6 mm (W) x 64.8 mm (H) x 42.3 mm (D) |
| Weight | 275g (body, battery and media) | |
| Operating Environment | Temperature | 0 - 40? (operation) / -20 - 60? (storage) |
| Humidity | 30 - 90% (operation) / 10 - 90% (storage) | |
- Body
- Lens cap
- Lens cap strap
- Li-50B
- F2AC
- USB/Video Multi cable
- Shoulder strap
- CD-ROM(ib and OLYMPUS Viewer2)
- Instruction manual
- Warranty card.
